Backpack-type mobile robot
Latent Lifting Mobile Robot B-BQP1
Product Features
Rated Load (kg)
1000/Customizable
Maximum Speed (m/min)
120
Duration (h)
8
Application Fields
Heavy Industry
Automotive Manufacturing Industry
Photovoltaic Industry
Lithium Battery Industry
Warehousing and Logistics
Product Advantages
120
Compact and flexible, fast running speed (m/min)
Energy saving and environmental protection
Uses efficient and safe lithium batteries, low operating cost
Multiple interfaces
Reserved multiple smart data interfaces to adapt to smart factory needs
Wireless communication
Uses intelligent wireless communication scheduling system to achieve speed synchronization for all AGVs
Product Features
Intelligence and Reliability
Comprehensive Intelligent Navigation
Flexibility and Scalability
Efficient Task Scheduling
Multi-Scenario Adaptation Capability
Precise environmental perception, maximizing space utilization
Product Parameters
Basic parameters
| Product model | Latent jacking mobile robot B-BQP1 |
|---|---|
| Overall dimensions | 940*650*250 |
| Turning radius (mm) | rotate in place |
| Rated load (kg) | 1000/Customizable |
| Navigation method | QR code/laser |
| Driving mode | differential speed |
| Lifting stroke (mm) | 60/Customizable |
| Assembly method | Bearing and jacking up |
Sport performance
| Walking speed (no load) (m/min) | 120 |
|---|---|
| Climbing ability (70% load) (°) | 5 |
| Positioning accuracy (mm) | ±5 |
| direction of travel | bidirectional |
