Backpack-type mobile robot
Dual-lift Combined Loading Mobile Robot L-UMP1+2H
Product Features
Rated Load (kg)
1000+3000/Customizable
Maximum Speed (m/min)
60
Duration (h)
8
Application Fields
Automotive Industry
Product Advantages
±5
High-precision Collaboration
6t
High Load Capacity
Product Parameters
Basic parameters
| Product model | L-UMP1+2 |
|---|---|
| Overall dimensionsL*W*H(mm) | 3300*2000*850/Customizable |
| Customizable | 4500 |
| Rated Load (kg) | 1000+2000/Customizable |
| Navigation method | Magnetic stripe/magnetic nail/ribbon/laser |
| Driving mode | Differential / Steering Wheel |
| Lifting stroke (mm) | Customized on demand |
| Assembly method | Lifting and carrying on the back |
Sports Performance
| Walking speed (no load) (m/min) | 60 |
|---|---|
| Climbing ability (70% load) (°) | 5 |
| Positioning accuracy (mm) | ±5 |
| Direction of travel | Omnidirectional |
