Autonomous forklift
Forklift F-BRS2
Product Features
Rated load (kg)
2000
Maximum speed (m/min)
90
Battery life (h)
8
Application Fields
Heavy industry
Automotive industry
Photovoltaic industry
Lithium battery industry
Product Advantages
Autonomous obstacle avoidance
It can autonomously avoid pedestrians or other dynamic obstacles.
Intelligent recognition
Intelligent identification of goods/application scenarios
±10
Positioning accuracy
12%
Climbing ability (70% load) (%)
Product Features
Real-time monitoring
Real-time monitoring of vehicle location and status
Collective scheduling
Large-scale collective scheduling of vehicles
Multiple security safeguards
Sports collision prevention, contact collision prevention, emergency braking, safe distance
Virtual Road Planning
The robot's movement trajectory can be planned by means of drawing lines, allowing the robot to travel along the specified route.
Product Parameters
Basic parameters
| Product model | Stacker Forklift F-BRS2 |
|---|---|
| Overall dimensions (l1*b1*h1)(mm) | 2169*963*2015 |
| Weight (including battery) (kg) | 1390 |
| Rated load (kg) | 2000 |
| Navigation method | laser |
| Load center distance (mm) | 600 |
| Lifting height (h3+h13)(mm) | 3000 |
| Maximum height of the mast during operation (h4) (mm) | 3580 |
| Fork dimensions (s/e/l) (mm) | 55/180/1150 |
| Fork outer width (b5)(mm) | 560-680 |
| Applicable pallet size (mm) | —— |
Sport performance
| Walking speed (no load) (m/min) | 90 |
|---|---|
| Climbing ability (70% load) (%) | 12 |
| Positioning accuracy (mm) | ±10 |
| Direction of travel | One-way/Two-way |
| Rotational ability | Spin/turn in place |
