Autonomous forklift
Counterbalanced Forklift S-BSS5
Product Features
Rated load (kg)
5000
Maximum speed (m/min)
90
Battery life (h)
8
Application Fields
heavy industry
special vehicles
industry
Lithium battery industry
Product Advantages
360°+3D laser obstacle avoidance
Autonomous obstacle avoidance
0.2-0.4m/s
turning speed
≤10mm
Allowed groove width
±10mm
Parking accuracy
5%
Climbing ability
3m
lifting height
Product Features
SLAM laser navigation mode
Laser navigation methods are customized on demand
3D visual recognition
Pallet recognition
Multiple security safeguards
Motion collision prevention, contact collision prevention, emergency braking, safe distance
Adapt to complex environments
Suitable for complex and changeable outdoor working environments, it demonstrates excellent adaptability and stability.
Product Parameters
Basic parameters
| Product model | Counterbalanced forklift S-BSS5 |
|---|---|
| Overall dimension (l1*b1*h1)(mm) | 4435*1600*2141/Customizable |
| Self-weight (including battery) (kg) | ＜8500 |
| Rated Load (kg) | 5000 |
| Navigation method | laser |
| Load center distance (mm) | 850 |
| Increased height (h3+h13)(mm) | 3741 |
| Maximum height of the mast during operation (h4) (mm) | 2141 |
| Fork dimensions (s/e/l) (mm) | 45/125/1070(可定制） |
| Fork outer width (b5)(mm) | 400-1300 |
| Applicable pallet size (mm) | —— |
Sports Performance
| Walking speed (no load) (m/min) | 90 |
|---|---|
| Climbing ability (70% load) (%) | 5 |
| Positioning accuracy (mm) | ±10 |
| Direction of travel | Unidirectional/Bidirectional |
| Rotational ability | Rotate/turn in place |
