Autonomous forklift
Pallet Jack F-BSC1
Product Features
Rated load (kg)
1500
Maximum speed (m/s)
1.5
Battery life (h)
6
Application Fields
Heavy industry
automotive industry
Photovoltaic industry
Lithium battery industry
Product Advantages
360°
360° Laser Protection and Obstacle Avoidance
±10mm
Parking accuracy
≤10mm
Allowed groove width
Product Features
SLAM laser navigation mode
Laser navigation methods are customized on demand
Compact design
Supports handling of multi-specification pallets, applicable to low-position operation handling, short-distance transportation, with a compact design, suitable for narrow spaces, and has the smallest turning radius.
Multi-dimensional protection
Safety physical contact edges, emergency stop buttons, status lights, voice announcements, providing VMT real-time operation status and safety protection in multiple directions
Task Scheduling and Multi-Machine Collaboration
Product Parameters
Basic parameters
| Product model | F-BSC1 |
|---|---|
| Overall dimensions (l1*b1*h1)(mm) | 1607*829*1910/Customizable |
| Weight (including battery) (kg) | 420 |
| Rated load (kg) | 1500 |
| Navigation method | laser |
| Load center distance (mm) | 600 |
| Lifting height (h3 + h13) (mm) | 200 |
| Maximum height of the mast during operation (h4) (mm) | —— |
| Fork dimensions (s/e/l) (mm) | 75/170/1150 |
| Fork outer width (b5)(mm) | 560-680 |
| Applicable pallet size (mm) | 1200*1200 |
Sports Performance
| Walking speed (no load) (m/min) | 90 |
|---|---|
| Climbing ability (70% load) (%) | 5 |
| Positioning accuracy (mm) | ±10 |
| direction of travel | One-way/Two-way |
| Rotational ability | Rotate/turn in place |
